Abstract
We have been discussing the validity of using the horizontaltovertical spectral ratios (HVRs) as a substitute for Swave amplifications after Nakamura first proposed the idea in 1989. So far a formula for HVRs had not been derived that fully utilized their physical characteristics until a recent proposal based on the diffuse field concept. There is another source of confusion that comes from the mixed use of HVRs from earthquake and microtremors, although their wave fields are hardly the same. In this study, we compared HVRs from observed microtremors (MHVR) and those from observed earthquake motions (EHVR) at one hundred KNET and KiKnet stations. We found that MHVR and EHVR share similarities, especially until their first peak frequency, but have significant differences in the higher frequency range. This is because microtremors mainly consist of surface waves so that peaks associated with higher modes would not be prominent, while seismic motions mainly consist of upwardly propagating plain body waves so that higher mode resonances can be seen in high frequency. We defined here the spectral amplitude ratio between them as EMR and calculated their average. We categorize all the sites into five bins by their fundamental peak frequencies in MHVR. Once we obtained EMRs for five categories, we backcalculated EHVRs from MHVRs, which we call pseudoEHVRs (pEHVR). We found that pEHVR is much closer to EHVR than MHVR. Then we use our inversion code to invert the onedimensional Swave velocity structures from EHVRs based on the diffuse field concept. We also applied the same code to pEHVRs and MHVRs for comparison. We found that pEHVRs yield velocity structures much closer to those by EHVRs than those by MHVRs. This is natural since what we have done up to here is circular except for the average operation in EMRs. Finally, we showed independent examples of data not used in the EMR calculation, where better ground structures were successfully identified from pEHVRs again. Thus we proposed here a simple empirical method to estimate Swave velocity structures using singlestation microtremor records, which is the most costeffective method to characterize the site effects.
Introduction
It is essential to evaluate the subsurface structure properly and validate previously proposed structures based on geological data and boring explorations with the observed seismic and nonseismic data for the quantitative prediction of ground motions in urban areas. There are plenty of methods to evaluate subsurface structures that may reproduce observed site characteristics of observed ground motions. However, there are not so many methods that can reliably determine Swave velocity structures down to the seismological bedrock, where the Swave velocity reaches 3.0 km/s or higher. Array measurements of microtremors to obtain phase velocities of propagating surface waves (e.g., Horike 1985; Okada 2003) have been successfully utilized to invert Swave velocity structures down to the seismological bedrock for more than three decades. Several applications of the method at different sites (e.g., Picozzi et al. 2009; Prieto et al. 2009; Stephenson et al. 2009) show the robustness of the method under various environments. Recent advances by Cho et al. (2006) and Tada et al. (2007) as a natural extension of the pioneering work of the socalled SPAC method by Aki (1957) provide us quite a strong tool for dispersion analysis. The downside of these array methods is that we need to deploy as many stations as possible for the precise determination of phase velocity at one frequency band and the array size must be increased in proportion to the targeted depth. As the array size is increased, the fundamental assumption of horizontally homogeneous layering would be difficult to expect. Also these array methods need very lownoise sensors with high coherence, especially in the long period range.
The spectral ratio approach with a reference site for seismic motions, either on the surface or inside the borehole, can be quite effective for obtaining a reliable Swave velocity structure when combined with a standard inversion technique such as genetic algorithm or simulated annealing. However, the spectral ratio approach with respect to the rock outcrop reference site, sometimes called the standard spectral ratio (SSR) method, will fail to provide reasonable site amplification either when the reference site is not sufficiently close to the target site or when the reference site is not close the seismological bedrock in terms of its Swave velocity. The socalled generalized spectral inversion method (Andrews 1986) will provide better site amplification characteristics if we find a good reference site among stations used because the generalized inversion makes use of all the data at once with proper attenuation correction and so the distance between the reference site and the target site is not an issue. Also once the inversion analysis is done, we can select the best site for reference, that is, the smallest amplification site with flat frequency dependence. In Kawase and Matsuo (2004) and following Nakano et al. (2015), the site amplification factors for KNET, KiKnet, and the JMA Shindokei network relative to the seismological bedrock outcrop at the reference site (YMGH01) were obtained and then used to invert Swave velocity structures at these sites.
As for the surfacetoborehole spectral ratio method, there is no problem for distance since the horizontal location of two sensors should be close together in a horizontal space. However, it is also quite a common situation to have a reference site not close to the seismological bedrock depth, especially for deep sedimentary basin sites. Even if the borehole station were well within a seismological bedrock formation, the surfacetoborehole spectral ratio is contaminated by the reflected phase at the free surface (e.g., Steidl et al. 1996; Satoh et al. 1997), which sometimes makes frequencies and amplitudes of peaks unstable for different clusters of sources.
Recently, using the crosscorrelation of two stations the socalled Green’s function retrieval method based on the diffuse field concept (DFC) is commonly applied to both seismic data and longduration of microtremor data (e.g., Campillo and Paul 2003). The dispersion characteristics of the obtained Green’s functions can be used to determine the averaged Swave velocity structure between two stations. This is quite a powerful method to determine a velocity structure averaged over the whole path between two stations; however, it does not provide a velocity structure immediately below the observed site. Besides, it may need to measure microtremors for sufficiently long duration (from several weeks to months) to get stable results.
After successful application of the crosscorrelation analysis of earthquake and microtremor data, it is natural to make two stations coincide with each other, that is, to utilize the autocorrelation of a singlestation measurement. In the autocorrelation approach, we can determine the velocity structure immediately below the observed site because of the direct correspondence of the imaginary part of the Green’s function to the spectral energy density (SánchezSesma et al. 2011). As a pioneering work, Margerin et al. (2009) showed that after sufficient lapse time from the onset of the Swave the late coda can be considered to be in the diffuse field regime. Then, Kawase et al. (2011) extended the idea of DFC to the stack of horizontaltovertical ratios of earthquakes (EHVR) and provided a simple theoretical formula assuming equipartition of energy in the incident waves at the bedrock (i.e., equipartition inside the halfspace). It turned out that this is a powerful tool to determine the Swave velocity structure below the observed site of earthquakes down to the seismological bedrock, as evidenced by Ducellier et al. (2013), Nagashima et al. (2014, 2017) and Fukihara et al. (2015).
Well before the advent of the application of DFC to EHVRs as mentioned above, SánchezSesma et al. (2011) applied the concept to the horizontaltovertical ratios of microtremors (MHVR) to derive a formula with horizontal and vertical Green’s functions of a point force on the surface. This theoretical formula provides the final solution for the longlasting debate on the interpretation of MHVR (e.g., Bard 1999; BonnefoyClaudet et al. 2004) that began from the initial proposal by Nakamura (1989). The DFC theory for MHVR can be used for the velocity structure inversion. The validation studies of this DFC interpretation of MHVR can be found in Salinas et al. (2014), Kawase et al. (2015), and Lontsi et al. (2015). Recently GarcíaJerez et al. (2016) show a new calculation scheme using residue integrals, which is much more efficient in computing Green’s functions and so they used it for velocity inversion.
Even though the calculation method for MHVR implemented by GarcíaJerez et al. (2016) is more efficient than the ordinary wavenumber integration scheme, still it is quite timeconsuming because of the inevitable summation to account for multiple contributions of poles in the wavenumber domain. On the other hand, the theory for EHVR is easy to calculate because we need to consider body wave contributions only in one wavenumber. Therefore, the inversion for EHVR is much more efficient than that for MHVR. However, in terms of field measurement effort, a temporal singlestation deployment of microtremor measurements for MHVR is much easier and less costly than a longlasting deployment of seismic motions for EHVR.
That is why we have proposed here a new method in which empirical translation from MHVR to EHVR is performed based on the observed spectral ratio between EHVR and MHVR at the same site, which is called EMR. EMRs are calculated as the averaged values from observed data for different categories classified based on their peak MHVR frequencies. The resultant HVRs, called pseudoEHVRs or pEHVR here, show quite similar characteristics to the observed EHVRs and so the inverted structures from pEHVRs are also quite similar to those from the observed EHVRs.
Method and data
Earthquake data
After the 1995 Hyogoken Nanbu (Kobe) earthquake, several nationwide strong ground motion observation networks have been deployed, and data from KNET (Kinoshita 1998) and KiKnet (Aoi et al. 2000; Okada et al. 2004) were used here. These are operated and distributed by the National Research Institute for Earth Science and Disaster Resilience (NIED). Among these KNET and KiKnet measurement sites, which are around 1700 sites in total, we observed microtremors (ambient noises) at 100 sites by our own efforts from 2000 to 2015. The locations of the sites considered in this study are shown in Fig. 1 and tabulated as Table 1. In Table 1, the earthquake event information, namely hypocentral distance ranges and numbers of event at each site, is added. There are no specific reasons to select these sites.
Measured earthquake records are analyzed according to the calculation flow here. First we select the earthquake data from the database provided by NIED, which contains source information determined by the Japan Meteorological Agency (JMA). Then, we cut out an Swave record section from the observed data file based on the Swave onset calculated from JMA source information and JMA’s travel time table (the socalled JMA2001 table, JMA 2001). The duration of the section is fixed to be 40.96 s. We also cut out another successive 40.96 s record section as a coda part to compare its spectral characteristics to the Swave part. After the extraction of these two record sections, we calculate their Fourier spectra and then take a spectral ratio of rootmeansquare (RMS) values of two horizontal components with respect to the vertical component to obtain the earthquake horizontaltovertical ratio (EHVR hereafter). Once all the records are analyzed, then we calculate the average of all the EHVRs to obtain the average and the average ± one standard deviations. The average operation here is not the one that the theory of the diffuse field suggests (SánchezSesma et al. 2011; Kawase et al. 2011), in which the average of the normalized spectra for each component should be calculated first and then a ratio between horizontal and vertical components are taken. The reason why we calculate the ratio first is because we would like to check the range of variation of EHVRs for different earthquakes. We confirmed that the averaged EHVRs for these two different ways of calculation are almost the same to each other.
In this research, we analyzed earthquake motions of peak ground acceleration (PGA) from 1.0 to 50.0 cm/s^{2} (0.01 m/s^{2}) among measured earthquake records. This is because the Swave may not be clear in seismic motion records if PGA is less than 1.0 cm/s^{2} and earthquake records exceeding 50.0 cm/s^{2} may show nonlinear behavior of the underground structure. Moreover, seismic motions of earthquakes exceeding the JMA magnitude M_{JMA} 6.5 are excluded from analysis to remove earthquake records with significant long period contribution through the excitation of basininduced or basintransduced surface waves, since our simple theoretical EHVR formula is derived by considering only body waves.
The portion before arrival of the Pwave is considered as a noise part, up to 40.96 s after the Swave onset as an Swave part, and 40.96 s following the Swave part as a coda part as mentioned before. The measured waveform at one of the KNET sites, EHM012, is shown in Fig. 2 as an example. Data with length less than 40.96 s are padded with zeros at the end. Spectrum analysis is carried out both in Swave and coda parts, as well as the noise part to check a signaltonoise ratio. A cosineshaped taper is added to both ends before the fast Fourier transform (FFT). Its length is set to be 10% of the data length for the noise part and 2.0 s for the Swave and coda parts. For KNET data, Fujiwara et al. (2007) showed that both old instruments until 2002–2006 (KNET95 type) and replaced instruments after that (KNET02 type) have flat response up to 30 Hz. Since the sampling rate of KiKnet stations is 200 Hz, we can also expect flat response at least up to 30 Hz.
The time history waveform of three components, namely north–south (NS), east–west (EW), and up–down (UD), are transformed into the frequency domain by FFT. Spectra of earthquakes where the signaltonoise ratio (SNR) is 2 or more are used to calculate average EHVR. Before taking the ratios, three components of the Fourier spectra are smoothed using a 0.1Hz Parzen window. We have confirmed the stability of the averaged amplitude irrespective of the choice of the bandwidth from 0.0 to 0.3 Hz.
The individual spectral ratios of NS/UD and EW/UD showed a good match as a whole, although there are a couple of sites that showed a difference more than twice (or half) around the first peak frequency. This kind of directional dependence suggests the effect of 2D/3D surface topography or irregularity in the basin structure (Matsushima et al. 2014). Since we are taking the RMS horizontal amplitude to obtain EHVR, the influence of the directional dependence would be minimal. Figure 3 shows the EHVRs of each observed earthquake and the average EHVR at EHM012 as an example. The black lines are the individual EHVRs (RMS/UD) of earthquakes and the red line is their average (orange lines: average ± one standard deviation). We can see that the EHVRs of individual earthquakes share a common shape, and the average EHVRs of both the Swave part and the coda part are quite similar to each other. The latter phenomenon was already reported in Satoh et al. (2001) for about ten sites in the Sendai basin. It should be noted, however, the deviation from earthquake to earthquake is larger in the coda part, especially in the lowfrequency range. The coda part is considered to be stable in amplitude because of multiple scattering with different directions of arrival, but the Swave part is found to be as stable as or more stable than the coda part in terms of the HVRs. Please note that the coda part here is just a successive section of record immediately after the Swave part with the same durations of 40.96 s and no dependence with respect to the source–site distance or the S–P time is considered as is usually adopted in the coda study.
Microtremor data
Microtremor observation at KNET and KiKnet sites was done by using an SMAR6A3P equipped with three component movingcoil type accelerometers with lownoise amplifiers from Mitutoyo Corporation, in which the data logger was replaced by LS8800 with 24bit A/D converters from Hakusan Corporation. The data sampling is set to be 100 Hz. Typically, measurement was done in a day time with the duration of 15–20 min at one site (30 min at a noisy site).
Measured microtremor records are analyzed according to the calculation flow here. First the whole continuously observed records with 900–1200 s in duration are subdivided into record sections of 40.96 s by overlapping 50%. We make a list of all the record sections in descending order based on the three components RMS amplitudes and then see its shorttime average (STA)/longtime average (LTA) ratio for the first best 15 segments. If the STA/LTA ratio is significantly larger than the other segments selected, we discard that segment and choose another segment (with slightly higher RMS amplitude) on the list until we select 15 segments. Then we visually inspected these 15 waveforms and if we found a segment or segments with some significant timevarying noises, we discarded and replace it by another better segment from the list. Figure 4 shows the measured microtremor waveform and sections used at the same site for earthquake example, EHM012.
As is the earthquake data analysis, three components are used to analyze, two horizontal components of which are used to calculate their RMS value. Then microtremor HVR (hereafter MHVR) is calculated as a ratio of RMS/UD. Finally, the MHVRs calculated for each segment are averaged over fifteen segments. Smoothing on the Fourier spectra is obtained by a 0.1Hz Parzen window as is the earthquake data analysis. Also a cosine taper of 2.0 s is added to both ends of the time history before FFT.
There is not much difference between the NS/UD and EW/UD of each site, as is the case of earthquake motions. Figure 5 shows the MHVRs of individual segments (RMS component, black lines), the averaged MHVR (red line), and the average ± one standard deviation (orange line) at the site EHM012 as an example. As is well known, the MHVRs are quite stable with time.
Velocity inversion using the theory for EHVR
Since we are applying the same inversion procedure developed for the EHVR by Nagashima et al. (2014, 2017), we only briefly describe the basic explanation of the assumptions and the method used.
First we summarized basic formulas to calculate the theoretical EHVR based on DFC. Under the assumption of DFC and subsequent energyequipartitioned condition, we can show that the diffusedwave energy spectra E(P, ω) at position P would be proportional to the normalized autocorrelation of observed displacement u(P, ω)^{2}, which in turn would be proportional to the imaginary part of the Green’s function at P as
For EHVR coming from a farfield source, following Claerbout (1968), we can write
where ρ_{H}c_{H} is the impedance of the halfspace and TF(ω) is the transfer function of the corresponding body wave. Therefore, we can get a simple formula for the surface observation of seismic motions as
where α_{H} and β_{H} are the P and Swave velocities of the halfspace, respectively. In this case, onedirectional HVR (i.e., NS/UD and EW/UD) calculation is assumed (e.g., Matsushima et al. 2014).
EHVR inversion
The inversion scheme used here is basically the same as those proposed by Nagashima et al. (2014, 2017), who extensively studied the velocity structures at the MYG004KNET site and its neighboring areas using a temporary deployment of aftershock observation for the 2011 Tohoku earthquake. For the inversion of Swave velocity structures, they used the scheme proposed by Yamanaka (2007), the socalled hybrid heuristic search (HHS) method. The method does not require an initial model, but it would be better to have one to constrain the searching range of parameters. For KNET sites we have Swave velocity information of downhole P and Swave logging down to 20 m at most, while for KiKnet sites we have them down to the borehole sensor depths, typically 100–200 m. In the Swave velocity inversion using EHVRs, we need to determine P and Swave velocities down to the seismological bedrock whose Swave velocity would be more than 3 km/s, as shown in Eq. (3). This makes possible to use not only peak frequencies but also their amplitude to reproduce observed EHVRs. For deep basin structures at KNET and KiKnet sites, we can refer to the JSHIS model of the shallow (< 10 km) crust, which can be downloaded from the portal site of JSHIS (http://www.jshis.bosai.go.jp/en/, last accessed on 2017/01/28). Pwave velocities are not the target of inversion but translated from the inverted Swaves based on the empirical relationship. We assume 1.1% damping for all the layers.
The residual (misfit) function to optimize is shown in Eq. (4), where the residual is normalized by the frequency f because equal sampling in frequency from FFT makes relatively increased numbers of constraint in the higher frequency range
Although for deep basin structures at KNET and KiKnet sites we refer to the JSHIS model in Japan, the Swave velocity of the topmost layer in the JSHIS database at a KNET site is not always close to the Swave velocity of the bottommost layer of the boring data since the depth of the KNET boring is only 20 m at most. Thus, we need to introduce intermediate layers whose Swave velocities are linearly increasing with depth with 200 m/s increment in between the bottommost layer of the boring data and the topmost layer of the JSHIS database. In Table 2, we show an example of such an initial model creation process for EHM012.
We set the searching range of ± 30% for boring Swave velocity data (while the layer thickness is fixed) and no range for JSHIS thickness data (while the Swave velocity is fixed). No range for thickness and velocity is assumed for the intermediate layers in between.
In Fig. 6, we show matching of EHVRs at EHM012, a convergence path for 200 generations, and the shallow and deep Swave velocity structures obtained, as an example. Blue lines in the last two panels are those for different trials with different initial sets of genes and green lines are for the initial model. We can see nice matching of the observed EHVR and very stable results in terms of obtained Swave velocities for different trials.
Here we should emphasize the importance of the whole basin structure modeling down to the seismological bedrock in the EHVR inversion. As shown in the theoretical derivation of DFC, namely Eqs. 1–3, EHVR depends on the equipartitioned energy ratios at the seismological bedrock, α_{H}/β_{H}, and the transfer functions of P and Swaves from there to the surface. This means that even in a high frequency range EHVR would be a function of the deep basin structure, not only a function of shallower sediments above the engineering bedrock.
To show the effects of a deep basin structure on EHVR in the high frequency range, we plot results of a parametric study in Fig. 7. We use the bestfit model with 14 layers as a reference for MYG004 (Nagashima et al. 2014, 2017) and omit two layers in each step from the bottom of the reference model. As the bottommost P and Swave velocities decrease, the peak in the lower frequency range disappears, as expected. However, not as expected, the peak and trough amplitudes in the higher frequency range increase strongly at the same time. This means that we should not invert only shallow sedimentary layers down to the engineering bedrock by using EHVR in the high frequency range as a target.
Results
EHVR and MHVR
Figure 8 shows comparisons of EHVRs and MHVR at six sites in Ehime Prefecture as an example. As pointed out before, EHVRs of the Swave part and those of the coda part match with each other at most of the sites. The EHVR amplitude of the coda part tends to be a little smaller than that of the Swave part, which is also pointed out in Satoh et al. (2001). This could be the effect of further energy scattering with time.
Comparison of EHVRs of the Swave parts and MHVRs between 0.2 and 20.0 Hz shows that at most of the sites these two ratios are very close to each other, especially the amplitude and the frequency of the first peak, as seen in EHM08, EHM011, and EHM012 in Fig. 8. On the other hand, there are several sites where the HVR peak frequency is close, but the amplitude is different or both are different, for instance EHM013 and EHM016. The notable difference is, however, that the EHVR amplitude after the first peak is much larger than that of the MHVR in general and sometimes it shows several clear peaks after the first one while the MHVR has smoothly varying characteristics in higher frequencies, as seen in EHM011. This kind of difference is exactly what we should expect due to the different nature of the wave field for microtremors and earthquakes.
Empirical EMR
The comparisons between EHVRs and MHVRs show that they are more or less similar until the fundamental peak frequency but that they are significantly different in the frequency range higher than that. Therefore, a way to extract a statistically significant trend in the difference between EHVRs and MHVRs is investigated. If we find a significant but common trend between EHVRs and MHVRs in all the sites, it means that we can convert MHVRs to equivalent EHVRs. To this end, we calculate the earthquake/microtremor ratio, EMR hereafter; the ratio of the average EHVR with respect to the average MHVR for each site as follows
Figure 9 shows EMRs for individual sites and the EMR averaged over all the sites used, together with the average ± one standard deviation. We found that the EMR exceeds 1 from 1 to 30 Hz and that the maximum is around 10 Hz. This means that the amplitude of EHVR is larger than MHVR for frequencies larger than 1 Hz, which is a direct consequence of the spectral difference shown in the previous section. However, these raw EMRs show large variations from site to site so that correction by using this simple averaged EMR may not be so meaningful.
When we look at the spectral comparison for individual sites in Fig. 8 and other sites omitted here, we can see clear frequency characteristics in the difference between EHVR and MHVR as mentioned before. Assuming that the fundamental peak frequencies of EHVR and MHVR are basically the same, which should reflect the specific velocity structure at that site, we can expect similar spectral characteristics in the EMRs for sites with similar fundamental peak frequencies. This is because EMRs are a direct consequence of the wave field difference of earthquake and microtremor ground motions in the same velocity structure. Therefore, the average EMR for a normalized frequency is derived by reading the fundamental peak frequency of MHVR and normalizing the frequency of EMR with respect to this fundamental peak frequency. To suppress some spurious peaks, we use a 0.3Hz Parzen window on MHVR when we read the fundamental peak frequency. Here, from a practical view point, we would like to restrict EMR calculations for the sites with a clear peak in between 0.2 and 20.0 Hz, so sites with MHVRs whose first peak is less than 2 in amplitude or whose first peak frequency is below 0.2 Hz or over 20.0 Hz are excluded from further analysis. As a result, 87 sites are selected for the averaging operation to get the normalized EMR. Figure 10 shows the average EMR with respect to the normalized frequency, together with the numbers of data used for averaging at each normalized frequency. If the fundamental peak frequency is high, then normalized frequency will become small and so such a site will contribute large numbers of data in the lower frequency range as we can see in the lower panel of Fig. 10. The interval along the horizontal axis differs for each sites because of normalization. To calculate the average EMR shown by the red line, the common interval Δ = 0.05 is designated and the logaverage is taken for all the data that fall into the frequency band ± 0.025 around the target frequency.
The frequency range of averaged EMRs extends into very low frequencies because of the data with higher (> 10 Hz) fundamental peak frequencies, and the average EMR is dropped to 0.3 at the highest frequency end because the number of data used is too small. The precision at both ends of the EMR is considered to be low as the interval between normalized frequencies would be too large when the peak frequency is below 1.0 Hz and the interval would be too small when the peak frequency is above 10 Hz. This means that the density of the frequency sampling from site to site can be considerably different because of the difference of the fundamental peak frequency. Also it would be more physically meaningful to have different correction factors depending on the fundamental peak frequencies. Therefore, these EMRs are categorized based on the fundamental peak frequency and the average EMR is calculated in each category. Figure 11 shows the average frequencynormalized EMRs in five peak frequency categories, namely 0.2–1, 1–2, 2–5, 5–10 and 10–20 Hz, together with their deviation ranges. We may get a smaller variation if we use a smaller frequency range but then the reliability of the average EMR will be decreased since the number of the sites in one category will be decreased. Table 3 shows the peak frequency range, number of measurement points, and interval Δ used in averaging in each category.
In Fig. 11, distinctive features are evident in different categories. Most notably, the EMR after the fundamental peak (i.e., f_normal ≧ 2.0) is especially large when the fundamental peak frequency is between 0.2 and 5.0 Hz (i.e., Category 1–3). Figure 12 shows the average EMRs of all the five categories, together with the whole average EMR without categorization (shown in Fig. 10). The average EMR in each category shows a similar amplitude in the frequency range with overlapping, but they are not exactly the same, especially when the normalized frequency is between 2 and 10. This means that average EMRs calculated in each category here should be used for better representation of EMRs, not the EMR without category classification.
We should note that the trend below 1 is somewhat different from category to category because we may have a secondary peak or peaks below 1 if we choose the fundamental peak frequency in the high frequency range (as Category 4 and 5), while we may hardly have a secondary peak or peaks below 1 if we choose the fundamental peak frequency in the lower frequency range (as Category 1 and 2). For Category 4 and 5, a high frequency peak has the highest amplitude but we may also have smaller peaks in the lower frequency range where we would have difference in EMR with smaller degree as shown in Fig. 12.
Validity of pEHVR
Once we obtain the average empirical EMR, we can translate MHVRs into pseudoEHVRs, or simply pEHVR. To see the validity of the EMR correction, we plot comparisons of EHVR, MHVR, and pEHVR in Fig. 13 for three representative sites in Category 1 (0.2–1 Hz peak) and Fig. 14 for three sites in Category 3 (2–5 Hz peak). As we can see in these figures, correction by EMR to MHVR is quite effective for reproducing EHVRs for most of the sites. When we compare correlations between MHVR and EHVR and between pEHVR and EHVR, significant improvement in the latter can be seen, especially for sites with high peak amplitude. Thus, EMR correction is meaningful to make MHVR closer to EHVR.
Inversions for MHVR and pEHVR
The effectiveness of EMR correction should be measured whether we can invert a similar velocity structure or not by using pEHVR as a substitute. In Fig. 15, we plot the same figures as in Fig. 6, but the results are plotted using pEHVR at EHM012. We can see that a similar velocity structure is inverted from pEHVR.
We should note that, if we directly substitute MHVR for EHVR and perform inversion analysis based on the theory of EHVR (i.e., Eq. 3), we can still find a very nice matching to data (i.e., MHVR). However, the resultant velocity structure is not exactly the same as the one obtained from the observed EHVR. This is because MHVR tends to be smaller than EHVR in the frequency range higher than the fundamental peak frequency as mentioned already, which makes impedance contrasts within layers smaller. Such an example is shown in Fig. 16 again for EHM012. The inverted structure by using MHVR has a high velocity layer between 5 and 20 m since the peak amplitude of MHVR is smaller than that of EHVR.
Finally, we performed the same inversion analyses using EHVRs, pEHVRs, and MHVRs for 87 sites in which the fundamental peak frequency falls into 0.2–20 Hz. To show the effectiveness of pEHVR for velocity inversion in comparison with the direct use of MHVR for all the sites, we plot averaged Swave velocities down to the depth z, Vs_z, of inverted structures using Eq. 6, where z is chosen to be 10, 30, and 100 m.
Here, \(H_{i}\) is the thickness of the ith layer, \({\text{Vs}}_{i}\) is the Swave velocity of the ith layer, and N is the number of layers down to the depth z.
Figure 17 shows the comparison of obtained Vs_10, Vs_30, and Vs_100 from MHVRs (left) and pEHVRs (right) in the vertical axes with respect to those from the true EHVRs in the horizontal axis. Here the identified results for EHVR are considered to be the correct solution. It is apparent that pEHVRs can reproduce very similar Vs_10 and Vs_30 and keep a 1–1 correspondence on the average. On the other hand, if we use MHVRs directly, the resultant Vs_10, Vs_30, and Vs_100 have a larger deviation and systematic bias at highervelocity (stiff) sites. This figure provides supporting evidence to promote our method in which we use empirical EMRs to translate MHVRs into pEHVRs.
Discussion
Validation in Sendai: data
So far, the operation is circular except for taking the average of EMRs for different categories based on fundamental peak frequencies of MHVRs. We need independent evidence to support the validity of the empirical EMR operation for better inversion of velocity structures.
To that end, we used seven sites in Sendai, Miyagi Prefecture, where prior underground structure information as well as earthquakes and microtremors data exist. Sendai City suffered from the 1978 Miyagiken Oki earthquake of M7.4 as well as the 2011 Off the Pacific Coast of Tohoku earthquake of M9.0. The city is located close to the active NagamachiRifu fault. Satoh et al. (2001a, b) carried out array microtremor measurements in Sendai and nearby cities to obtain the deep Swave velocity structures inside the Sendai basin, and the earthquake ground motions were also measured at the center of each array. The array measurement locations at Sendai are shown in Fig. 18. Among these sites, the same analysis for validation is conducted using earthquake and microtremor HVRs at seven sites, namely ARAH, MYG015, NAGA, NAKA, SHIR, TRMA, and TAMA. Although velocity structures at these sites are different from each other, the characteristics of the wave field either for earthquake or microtremors are considered to be basically onedimensional because of the isotropic nature of their HVRs.
Figure 19 shows the pEHVRs derived from MHVRs and EMRs, EHVR, and MHVRs at seven sites in Sendai. Compared to the observed ones, clear fundamental peaks exist in the low frequency range of 0.2–1.0 Hz in both MHVR and EHVR and the peak levels roughly agree at all the sites except for TAMA. However, upon closer inspection, the peak amplitudes of EHVRs are slightly smaller at NAGA and SHIR but that of EHVR is larger at TRMA. Furthermore, the amplitude levels of MHVR are much smaller than EHVRs at 1.0 Hz and above in all the sites. There is a peak near 3.0 Hz in EHVR at TAMA, but its amplitude is rather small and there is no corresponding peak in MHVR.
Next, pEHVR, which is calculated using MHVR and EMR that corresponds to a proper category for the fundamental peak frequency, and EHVR are compared. At ARAH, NAGA, NAKA, and MYG015, pEHVR and EHVR agree very well. The peak amplitude at about 3 Hz of pEHVR at SHIR exceeds that of EHVR since the peak amplitude of MHVR is already large, although in the frequency range from 1 to 3 Hz EMR correction did a reasonably good job. On the other hand, pEHVR at TRMA could not provide the correct second peak frequency at around 4 Hz, although the overall amplitude in the high frequency range becomes closer to the EHVR than that of MHVR is. Since no clear peaks are found in MHVR at TAMA, the site is excluded from underground structure identification.
Validation in Sendai: with a priori constraints
The underground structure models identified by Satoh et al. (2001a) are set as the initial models with a priori information, and the underground structure is inverted using the inversion method described above. Table 4 shows the initial models with a priori information. The bottom three layers are set to Vs = 850, 1700, and 3500 m/s in all the cases. The velocity structure of layers above the Vs = 850 m/s layer and the numbers of layers differ from site to site.
The same inversion scheme is carried out using EHVR, pEHVR, and MHVR as the target. The only difference is that the searching range in the inversion is limited to ± 30% of the initial model for all the layers because the initial values from Satoh et al. (2001a) would be more or less reliable.
First focusing on inversion results using EHVR as the target, the measured EHVR agrees better with the inverted result of EHVR than the initial model of EHVR for most of the sites, which is a natural consequence. The only exception is the amplitude at high frequency above 4.0 Hz at NAGA, where the inverted model cannot sufficiently reach the observed high amplitude. In Figs. 20 and 21, we show matching HVRs, convergence paths of residuals, and the final inverted velocity models for EHVR, pEHVR, and MHVR cases for MYG015 and TRMA.
Looking at the inversion results using pEHVR and MHVR at each site, the identified velocity structures from both pEHVR and MHVR are found to successfully reproduce the target HVRs. However, the resultant velocity structure from MHVR is not similar to that from EHVR, while that from pEHVR is much closer to that from EHVR, as can be seen in Figs. 20 and 21. At TRMA in Fig. 21, highfrequency amplitude in MHVR is much smaller than the EHVR so that the inverted shallow velocity structure from MHVR yields a strong velocity inversion (a highspeed layer in a shallower depth) at 20 m, which is softened in either the velocity structure from EHVR or that from pEHVR. Although figures are omitted, again inversion from pEHVR cannot explain the amplitude above 4.0 Hz at NAGA, as in the case of EHVR. Interestingly, however, inversion from MHVR can reproduce the amplitude above 4.0 Hz at NAGA, since the amplitude of MHVR does not show any prominent peaks in that high frequency range.
Validation in Sendai: without a priori constraints
Underground structure inversion without a priori constraint, such as PS logging data from boring, could be ideal when actually inverting the underground structure using pEHVR alone. To test the initial model dependence, the JSHIS underground structure model publicly available from NIED is used as the initial value. Table 5 shows the initial model based on JSHIS. There are only two layers with an Swave velocity (Vs) less than 1200 m/s in the JSHIS underground structure, which have Vs = 350 and 650 m/s, and so one layer with the initial Swave velocity Vs = 200 m/s is added to the surface of the model.
As in the previous section, EHVR, pEHVR, and MHVR are set as the target and ten independent HHS inversions are conducted for each target. The Swave velocity and layer thicknesses are considered as variables in all layers without setting any range of variation because the initial model information is not considered to be so reliable. However, the minimum Swave velocity at the surface layer is set to be Vs = 50 m/s for reality. Figures 22 and 23 show a comparison of inverted results at MYG015 and TRMA. We found that the matching for EHVR, pEHVR, and MHVR with the resultant inverted structures is in general as good as the case with the initial models. This means that initial model dependency is not so strong as long as we give sufficient space for variables. It is especially interesting to see the better matching of the inverted EHVR and pEHVR at NAGA; now both structures can reproduce a high amplitude peak at 4.0 Hz. The resultant residuals without a priori information are much smaller than those with a priori information.
Again looking at the velocity models from MHVRs, we found that they are different from the velocity models from EHVRs and pEHVRs, although their convergences are sometimes better than those of EHVRs and pEHVRs. This discrepancy suggests that it is not appropriate to directly substitute MHVRs in the inversion based on the diffuse field concept for earthquake ground motions.
Validation in Sendai: comparison
Three types of inversions are conducted by using EHVRs, pEHVR, and MHVR as a target with and without a priori constraints as the initial model. The inverted underground structures can reproduce the respective HVRs in these three identification types, either with or without a priori constraints. However, the resultant velocity structures are not necessarily the same. As before, the average Swave velocities at depths to 10, 30, and 100 m from pEHVRs and MHVRs are shown in Fig. 24 using the horizontal axis as those from EHVRs. The inversion results from pEHVR are closer to the inversion results from EHVRs than those from MHVRs. The same is true for the cases without a priori constraints, which is not shown here.
Several outliers’ site codes are shown in Fig. 24. SHIR is the site with the largest difference in Vs30 and Vs100 even for the pEHVR inversion, which is the direct consequence of the poor reproduction of EHVR as seen in Fig. 19. On the other hand, NAGA shows quite good correspondence for the pEHVR inversion, while it does poor correspondence for the MHVR inversion. For Vs10, the differences are relatively small, except for ARAH by the MHVR inversion where the amplitude in the frequency range higher than 3 Hz is deficient so that soft shallow layers are eliminated.
These results corroborate the two findings in the previous sections, namely “the underground structure inverted directly from MHVR could lead to a different structure” and “the underground structure inverted from pEHVR could give a structure closer to the one from EHVR”. Therefore, the effectiveness of the proposed method where MHVR is converted into pEHVR using empirical EMR has been demonstrated.
Finally, the residuals shown in Eq. 4 of the inverted results based on the two initial models with and without a priori constraints are compared in Table 6. Comparing the residual of EHVR for the initial models of Satoh et al. (2001a) and the residual of inversion from EHVR with a priori information, we found that the latter is smaller and so we might expect that the latter may be closer to the actual 1D underground structure for site amplification (as far as the assumption of the theory is fulfilled). Here we assume the latter inverted result as the representative underground structure at each site for further comparisons.
We should note here that the residuals of inversions without a priori constraints (i.e., only JSHIS model constraint) show much smaller values than those with a priori constraints. As mentioned before, this is because the searching space for the case without a priori constraints is much wider than that with a priori constraints so that the residuals were smaller. This is the case for not only EHVR but also for pEHVR and MHVR. However, the resultant velocity structure with smaller residuals is not necessarily close to the actual velocity structure. To see the source of the magic, we calculated the residual between the HVR of the representative underground structure (that is, the HVR from the inverted model from EHVR with a priori constraints) and HVRs of inverted models from EHVR, pEHVR, and MHVR without a priori constraints are calculated and shown in the parentheses in Table 6. Focusing on the residuals of inverted models using pEHVR and MHVR with respect to HVR of the representative velocity structure in the parenthesis, the residuals from pEHVR give much smaller residuals than those from MHVR. Therefore, inversion using MHVR as a substitute of EHVR yields an underground structure that reproduces MHVR well, but it does not mean that the resultant structure from MHVR is close to the actual underground structure.
Source of errors
All the good aspect of the study shown here are based on assumptions from DFC and so the validity of the method seems to depend on the diffusivity of the wave field that we are observing. Unfortunately, it is quite difficult to provide direct evidence of the diffusivity using the observed data since we cannot observe wave field under controlled condition in the real field. For example isotropic nature of energy distribution in threedimensional space, that is equipartition of seismic energy, cannot be easily observed because of the complex site effects near the observation point (See reviews in Kawase et al. 2015).
However, all the observational reports based on DFC unanimously shows that theoretical expressions based on DFC seem to work under variety of conditions even in the case with apparent violation of diffusivity. For example, the socalled SPAC method provides reasonable values of phase velocities of surface waves for most of the cases, even when the observed wave field may not be perfectly isotropic. This means that the formula derived from DFC is quite robust in the sense that we can extract some information of the medium from the wave field where only partially diffusive nature is established.
As a final note of caution, we must mention that our inverted solution from EHVR is nonunique in nature, since we are using nonlinear inversion scheme with HHS algorithm. It is obvious that our solution is constraint only by the target EHVR (or pEHVR) and the reference structure used, together with the searching ranges from the reference structure imposed in the inversion. Thus, we need to choose these values carefully and we have to pay attention to possible range of errors due to inherent nonuniqueness of the inversion. It is nonunique in nature; however, the strength of our EHVR inversion lies in its capability to obtain both Swave velocities and the thicknesses of the layers down to the bedrock at the same time, unlike the other methods with strong tradeoffs between them, because we use both amplitudes and peak/trough frequencies of EHVR to constrain the velocity profile.
Conclusions
In this study, we calculated the horizontaltovertical spectral ratios (HVR) from observed microtremors (MHVR) as well as those of observed weak earthquake ground motions (EHVR) and compared predominant peak frequencies and amplitudes at these peak frequencies of the MHVRs and EHVRs with those calculated theoretically from Swave velocity models based on the diffuse wave concept. When we compare MHVRs and EHVRs, we found that they share similarities but have significant differences in their shapes, especially after the fundamental peak frequency in MHVRs. This is because MHVR mainly consists of surface waves so that peaks associated with higher modes would not be as prominent as that of EHVR. We first searched for better 1D structures at each observed site by using the proposed HHS method of Nagashima et al. (2014, 2017) for observed EHVRs based on the theory from the diffuse field concept. As a result, we successfully identified a better ground structure for each observation site from the seismological bedrock to the surface.
After looking at the systematic differences in MHVRs and EHVRs, we tried to establish a new, simple method to estimate velocity structures using singlestation microtremor records since it is the most costeffective, noninvasive method to characterize site effects. To that end, we calculated EHVRtoMHVR ratios (EMRs) at 100 KNET and KiKnet sites in Japan to find that there are systematic difference in the observed EMRs. Using EMRs averaged over five different categories based on the fundamental peak frequency (f_peak) ranges of MHVRs as a function of the normalized frequency f/f_peak, we converted MHVRs to pseudoEHVRs by multiplying MHVRs with the average EMRs, which are found to have higher correlation with real EHVRs than MHVRs. Using these pseudoEHVRs, we can identify velocity structures from the seismological bedrock to the surface, with much better correspondence to the true structures than the direct use of MHVRs as substitutes. Independent evidence for the effectiveness of the pseudoEHVR approach is presented for sites in Sendai, Japan.
We should note that highfrequency EHVRs are not only controlled by the velocity structure shallower than the engineering bedrock but also by the deep basin structure because of higher mode contributions. This is a strong opposition to the idea that site effects can be modeled only by the shallower structure below a site (say, down to 30 m), if our primary concern is focused only onto the high frequency content.
What is remaining to investigate is the way to determine numbers of unknown parameters and their range of search under various practical situations where no or not plenty of a priori information exist. We also need to explore the possibility of simultaneous inversion for earthquake and microtremors data, velocity logging and microtremor data, or data on the surface and in the boreholes. For more accurate prediction of EHVR from MHVR, we need to collect further numbers of data for both MHVR and EHVR under variety of tectonic and geological conditions to propose more effective ways of categorization in EMR.
